        Inverex Nitrox INVEREX NITROX 3 KW – 24 V SOLAR INVERTER (SINGLE PHASE)

        Original price was: ₨ 230,000.Current price is: ₨ 200,000.

        Order on WhatsApp
        GUARANTEED SAFE PAYMENTS
        Jazz Cash, Easypaisa, Meezan Bank, and Bank Transfer logos
        Share it to:
        Variable Pricing

        Due to high market volatility, prices for our products are subject to change.

        Final Prices

        The actual price will be provided once the customer contacts our sales representative via WhatsApp.

        Deposit Requirement

        The product will be dispatched only after a partial deposit is made in our business account.

        Need a Complete Solar Installation?

        Looking for more than just solar equipment? Comfort Solar designs and installs customized on-grid, hybrid, and off-grid solar systems for homes and businesses in Islamabad, Rawalpindi, Wah Cantt, Taxila, and nearby areas. Visit our Solar Installation Services page or book a free indicative quotation today.

        Additional information

        Battery Type

        Lead-acid or Lithium-ion

        Battery Voltage Range (V)

        40-60

        Max. Charging Current (A)

        240

        Max. Discharging Current (A)

        240

        Charging Strategy for Li-ion Battery

        Self-adaption to BMS

        Number of Battery Input

        1

        Max. DC Input Power (W)

        15600

        Max. DC Input Voltage (V)

        800

        Start-up Voltage (V)

        160

        MPPT Voltage Range (V)

        200-650

        Rated DC Input Voltage (V)

        550

        Max. Operating PV Input Current (A)

        20+20

        Max. Input Short-Circuit Current (A)

        30+30

        No. of MPP Trackers/ No. of Strings per MPP Tracker

        2/1+1

        Rated AC Input/Output Active Power(W)

        12000

        Max. AC Input/Output Apparent Power(VA)

        13200

        Rated AC Input/Output Current (A)

        18.2/17.4

        Max. AC Input/Output Current (A)

        20/19.2

        Max. Three-phase Unbalanced Output Current (A)

        27.3/26.1

        Max. Continuous AC Passthrough (grid to load) (A)

        45

        Peak Power (off-grid) (W)

        2 times of rated power, 10S

        Power Factor Adjustment Range

        0.8 leading to 0.8 lagging

        Rated Input/Output Voltage/Range (V)

        220/380V, 230/400V 0.85Un-1.1Un

        Rated Input/Output Grid Frequency/Range (Hz)

        50/45-55, 60/55-65

        Grid Connection Form

        3L+N+PE

        Total Current Harmonic Distortion THDi

        <3% (of nominal power)

        DC injection current

        In

        Max. Efficiency

        97.6%

        Euro Efficiency

        97.0%

        Communication Interface

        WIFI, RS485, CAN

        Operating Temperature Range

        -40 to +60°C, >45°C Derating

        Permissible Ambient Humidity

        0-100%

        Permissible Altitude

        3000m

        Noise (dB)

        55

        Ingress Protection (IP) Rating

        IP65

        Inverter Topology

        Non-isolated

        Over Voltage Category

        OVC II(DC), OVC III(AC)

        Cabinet Size (WxHxD mm)

        386x660x253 (Excluding Connectors and Brackets), 700Wx575Hx297D, 838Wx568Hx323D

        Weight (Kg)

        35.2, 44.5, 73.7

        Type of Cooling

        Intelligent Air Cooling

        Warranty

        5 Years

        Grid Regulation

        IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105

        Safety/EMC Standard

        IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

        Description

        Are you searching for a reliable single-phase solar inverter for your home or small office? The Inverex Nitrox 3 KW – 24 V Solar Inverter, available at Comfort Solar, is the perfect solution. This advanced inverter is designed to provide superior performance and efficiency, ensuring your solar power system operates seamlessly.

        Key Features:

        • High Efficiency: Reaches a maximum efficiency of 97.6%, maximizing solar energy utilization.
        • MPPT Support: Supports up to 600 watts solar panel with 15600 watts MPPT.
        • High Capacity Solar Charger: Equipped with a 240 AMP solar charger for efficient charging.
        • Smart Monitoring: Features a smart PV monitoring platform and stick logger for comprehensive system tracking.
        • Multiple Parallel Support: Allows for the connection of multiple inverters in parallel.
        • Zero Export: Manages energy export to the grid for efficient energy use.
        • Communication Interfaces: RS485 and CAN for seamless monitoring and integration.
        • Robust Design: IP65 ingress protection for weather-resistant outdoor installations.
        • Generator Connection: Supports connection to a generator for added flexibility.
        • High Surge Endurance: Designed to withstand high surge currents, protecting your system.
        • High Power Factor: Ensures efficient energy conversion.
        • User-Friendly Interface: Touch screen display for easy operation and monitoring.
        • Internal Protection: Equipped with internal surge protection devices (SPDs) and a built-in AC breaker for enhanced safety.
        • Time of Use Settings: Six-time of use settings for customized energy management.
        • Dual 3 Phase Output: Provides dual three-phase output for versatile applications.
        • Warranty: 10-year warranty with a 5-year replacement term. Terms and conditions apply.

        Detailed Features:

        1. Efficiency and Performance: The Inverex Nitrox 3 KW inverter offers a maximum efficiency of 97.6%, ensuring your solar energy is converted efficiently. The MPPT support optimizes the performance of your solar panels, allowing up to 600 watts per panel with a total support of 15600 watts.
        2. Protection and Monitoring: Equipped with internal surge protection devices (SPDs) and a built-in AC breaker, this inverter safeguards your system against electrical surges and ensures safe operation. The zero export function allows for efficient management of energy exported to the grid, optimizing your energy consumption.
        3. Advanced Functions: The inverter supports the connection of multiple inverters in parallel, offering scalability for growing energy needs. It also supports generator connection, providing flexibility in power sources.
        4. Robust Design: With an IP65 rating, the Inverex Nitrox inverter is protected against dust and water, making it ideal for outdoor installations. The high power factor ensures efficient energy conversion, minimizing losses.
        5. User-Friendly Interface: Featuring a touch screen display, this inverter provides an easy-to-use interface for monitoring and managing your solar power system. The smart PV monitoring platform and stick logger offer comprehensive tracking of your system’s performance.

        Why Choose Comfort Solar? At Comfort Solar, we are committed to offering premium solar solutions tailored to your needs. Our Inverex Nitrox 3 KW – 24 V Solar Inverter is designed to deliver exceptional efficiency, reliability, and ease of use. By investing in our products, you are choosing sustainability and long-term energy savings.

        Call to Action: Ready to enhance your energy independence with our high-performance single-phase solar inverter? Visit comfortsolar.pk today to explore more about our products. For any inquiries or to place an order, contact us directly on WhatsApp at 03166225526. Don’t wait—empower your home with the best solar technology available!

        Delivery & Returns:

        • Standard Delivery: 4-5 days.
        • Warranty and Returns: 10-year warranty with a 5-year replacement term, and a 7-day return and exchange policy. Terms and conditions apply.

        Brand

        Inverex

        APT Inverex offers a variety of renewable energy products designed to enhance energy efficiency and promote zero-emission power solutions. Their product range includes photovoltaic systems, power backup solutions, and complete solar installations that cater to individual and industrial requirements. All products are geared towards reducing reliance on fuel-powered grids and supporting a sustainable future. These offerings from APT Inverex are available on our website, Comfort Solar, where customers can explore and select solutions that best fit their energy needs.
        Inverex solar energy logo in red rectangle with white text and graphics
        APT Inverex, established in 2007, is a company specializing in renewable energy solutions, particularly solar technology. They provide a wide range of products, including solar panels, inverters, and power backup solutions, catering to both residential and industrial needs. The company focuses on innovative, state-of-the-art engineering to promote sustainable energy use, offering comprehensive services from system design to installation and monitoring. APT Inverex aims to help customers transition from traditional energy consumption to becoming educated producers and consumers of green energy.
