Output Power: 23 kW
Max Efficiency: 98.6%
Max DC Input Current: 2 × 40A
AC Output Current: 34.9 A
MPPTs: 2 (multi-string input)
Built-in SPD II, DC switch, AFCI optional
Operating Temp: -25°C to +60°C
IP66 for outdoor installations
Size: 435 × 520 × 194 mm
Weight: 19 kg
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
Looking for more than just solar equipment? Comfort Solar designs and installs customized on-grid, hybrid, and off-grid solar systems for homes and businesses in Islamabad, Rawalpindi, Wah Cantt, Taxila, and nearby areas. Visit our Solar Installation Services page or book a free indicative quotation today.
| Max. DC Voltage | 1100 VDC |
|---|---|
| Start-up DC Voltage | 180 VDC |
| Rated Input Voltage | 630 VDC |
| Max. Number of PV Strings | 4 |
| MPPTs | 2 |
| Max. Input Current/MPPT | 2×32 A |
| Rated Output Power | 23 kW |
| Rated Apparent Power | 23 kVA |
| Rated Output Voltage | 380/400 VAC |
| Rated Output Current | 35 A |
| Rated Output Frequency | 50/60 Hz |
| Total Harmonic Distortion (THD) | < 3% |
| Power Factor | 0.8 (Adjustable) |
| Max. Efficiency | 98.6% |
| Euro Efficiency | 98.0% |
| Protection Degree | IP66 |
| Cooling Method | Intelligent Air Cooling |
| Operating Temperature | -30°C to +60°C |
| Operating Altitude | 4000 m (derating above 2000 m) |
| DC Switch | Yes |
| Anti-Islanding Protection | Yes |
| Reverse Polarity Protection | Yes |
| Insulation Resistance Detection | Yes |
| Leakage Current Suppression | Yes |
| AC Output Over Current Protection | Yes |
| AC Short Circuit Protection | Yes |
| Display Type | LED Indicators & APP |
| Communication Interfaces | RS485 / Wi-Fi / Optional 4G |
| Dimensions | 435 x 520 x 194 mm |
| Weight | 19 kg |
| Connectors | Plug-type (Tool-free installation) |
| AFCI | Optional |
Ideal for large commercial installations, the 23kW model provides excellent conversion efficiency, advanced protection, and stable grid support.
