₨ 189,750
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Max. DC input power | 4500 W, 5400 W, 7500 W, 9000 W |
|---|---|
| Max. DC Input Voltage | 550 V |
| Operation voltage range | 80 V – 550 V |
| MPPT working voltage range | 90 V – 550 V |
| Number of independent MPPT inputs 3 | 2/1+1 |
| MPPT max. current | 15 A / 15 A |
| Start-up voltage / Min. operating voltage | 100 V / 80 V |
| Nominal output apparent power | 3000 VA, 3600 VA, 4000 VA, 6000 VA |
| Max. output apparent power | 3300 VA, 4000 VA, 5500 VA, 6600 VA |
| Nominal Output Voltage | 230 V / 180 V – 280 V |
| Nominal output frequency | 50 Hz / 60 Hz |
| Rated output current | 13 A, 15.6 A, 22 A, 26 A |
| Max. Output Current | 14 A, 17 A, 24 A, 29 A |
| Power Factor | < 3% (Nominal Output) |
| THDi | L+N+PE |
| Grid system pattern | 8000 VA |
| Max. apparent power from utility grid | 28 A, 32 A, 48 A, 58 A |
| Max AC current from utility grid | 28 A, 32 A, 48 A, 58 A |
| Peak output apparent power | 4000 VA, 10s, 4600 VA, 10s, 5000 VA, 10s, 7000 VA, 10s |
| Output THDV | < 10ms |
| Automatic switch time | < 10ms |
| Battery Type | Li-ion / Lead-acid |
| Nominal battery voltage | 48 V |
| Battery Voltage Range | 40 V – 60 V |
| Max. charging voltage | 58 V (Configurable) |
| Max. charging/discharging current | 100 A |
| Battery capacity (AH) | 50-2000 |
| Charging Strategy for Li-ion Battery | Self-adaption to BMS |
| Charging strategy for Lead-acid Battery | Three-stage |
| Max. Efficiency | 97.5%, 98.0% |
| Europe efficiency | 94.0% |
| Max. battery to load efficiency | Yes |
| Anti-islanding Protection | Yes |
| Insulation impedance protection | Yes |
| RCD detection | Yes |
| PV reverse polarity protection | Yes |
| Output over voltage protection | Yes |
| Output over current protection | Yes |
| Dimensions (WxHxD) | 375/365/240 mm |
| Weight | 20 kg |
| Noise | < 25 dB |
| Operation temperature range | -25°C to +60°C |
| Heat dissipation mode | Natural |
| IP Class | 65 |
| Maximum altitude | 4000 m |
| Self-Consumption Night | Transformerless |
| Features | Yes |
| LCD Display | Yes |
| Communication Interface | WiFi/4G/USB/CAN/RS485 |
| Warranty | 5 years (standard) |
| Standards | OO, CEI 0-21, VDE-AR-N4105 |
