₨ 155,250
Your orders are shipped seamlessly between countries
You have the right to return your orders within 30 days.
Your payments are secure with our private security network.
| Maximum PV Input Power | 5500W, 7200W |
|---|---|
| Rated Output Power | 3600W, 4200W, 6200W |
| Maximum Solar Charging Current | 120A, 140A |
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC |
| Start-up Voltage/Initial Feeding Voltage | 90VDC/120VDC |
| MPPT Voltage Range | 90-450VDC |
| Number of MPPT Trackers/Maximum Input Current | 1/27A |
| Nominal Output Voltage | 230VAC |
| Output Voltage Range | 195.5-253VAC |
| Nominal Output Current | 15.7A, 18.2A, 27.0A |
| Power Factor | >0.99 |
| Feed-in Grid Range | 49-51±1Hz |
| Maximum Conversion Efficiency( Solar to AC) | 98% |
| AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC |
| Maximum AC Input Current | 30A |
| Nominal operating frequency | 50/60Hz |
| Surge Power | 12000VA, 6000VA, 7200VA |
| Output Waveform | Pure Sine Wave |
| Efficiency (DC to AC) | 94% |
| Nominal DC Voltage | 24VDC, 48VDC |
| Maximum Charging Current (Solar to AC) | 120A |
| Maximum AC Charging Current | 100A, 80A |
| Dimension, D x W x H (mm) | 590 x 390 x 208 |
| Net Weight (kgs) | 8.8, 9.3, 9.8 |
| Gross Weight (kgs) | 10, 11 |
| Communication Port | Rs232/WIFI/GPRS |
