₨ 295,000
🔹 Power Output: 8kW (Single-Phase)
🔹 Max PV Input: 12.8kW
🔹 Battery Compatibility: Lithium-ion & Lead-Acid (40-60V)
🔹 Charge/Discharge Current: Up to 190A
🔹 UPS Function: <4ms switch time for uninterrupted power
🔹 Efficiency: >96.9%
🔹 Surge Power Handling: 200% overload for 10 sec
🔹 Communication: Wi-Fi, GPRS, RS485, CAN for remote monitoring
🔹 Protection Features: AFCI, Ground Fault Monitoring, DC Reverse Polarity
🔹 Cooling System: Intelligent fan cooling
🔹 IP Rating: IP66 (Suitable for outdoor use)
📞 For Pricing & Installation: 0316 622 5526
🌍 Website: ComfortSolar.pk
📍 Islamabad, Pakistan
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Max. Apparent Output Power (Grid Side) | 3.3 kVA, 4 kVA, 5.5 kVA, 6.6 kVA |
|---|---|
| Max. Apparent Output Power (Back-up) | 2 times of rated power, 10 s |
| Rated Output Voltage (Back-up) | 1/N/PE, 220 V / 230 V |
| Rated Output Current (Back-up) | 13.6 A / 13.0 A, 16.4 A / 15.7 A, 22.7 A / 21.7 A, 27.3 A / 26.1 A |
| Recommended Max. PV Array Size | 10 kW, 12 kW, 6 kW, 7.2 kW |
| Max. Usable PV Input Power | 4.8 kW, 5.76 kW, 8 kW, 9.6 kW |
| Max. Input Voltage | 600 V |
| Rated Voltage | 330 V |
| Start-up Voltage | 90 V |
| MPPT Voltage Range | 90-520 V |
| Max. Input Current | 16 A / 16 A |
| Max. Short Circuit Current per MPPT | 24 A / 24 A |
| MPPT number/Max.input strings number | 2/2 |
| Battery Type | Li-ion / Lead-acid |
| Battery Voltage Range | 40-60 V |
| Max. Charge / Discharge Power | 3 kW, 3.6 kW, 5 kW, 6 kW |
| Max.charge/discharge current(A) | 112 A, 135 A, 70 A, 80 A |
| Communication | CAN/RS485 |
| Rated Output Power (Grid Side) | 3 kW, 3.6 kW, 5 kW, 6 kW |
| Operation Phase | 1/N/PE |
| Rated Grid Voltage | 220 V / 230 V |
| Rated Grid Frequency | 50 Hz / 60 Hz |
| Rated Grid Output Current | 13.6 A / 13.0 A, 16.4 A / 15.7 A, 22.7 A / 21.7 A, 27.3 A / 26.1 A |
| Max. Output Current (Grid Side) | 15 A, 20 A, 25 A, 30 A |
| Power Factor | >0.99 (0.8 leading – 0.8 lagging) |
| THDi | <2% |
| Input Voltage Range (Grid Side) | 187-253 V |
| Max. Input Current (Grid Side) | 20 A, 25 A, 32 A, 40 A |
| Frequency Range | 45-55 Hz / 55-65 Hz |
| Rated Output Power (Back-up) | 3 kW, 3.6 kW, 5 kW, 6 kW |
| Back-up Switch Time | <4 ms |
| Rated Frequency (Back-up) | 50 Hz / 60 Hz |
| Max. Output Current (Back-up) | 15 A, 20 A, 25 A, 30 A |
| Max. AC Passthrough Current | 35 A, 40 A |
| THDv (@linear load) | <2% |
| Max. Efficiency | >96.9% |
| EU Efficiency | >96.5% |
| DC Reverse Polarity Protection | Yes |
| Ground Fault Monitoring | Yes |
| Integrated AFCI (DC Arc-Fault Circuit Protection) | Yes (1) |
| Protection Class/Over Voltage Category | I/II (PV and BAT), III (MAINS and BACKUP and GEN) |
| Dimensions (W*H*D) | 406*560*205 mm |
| Weight | 24 kg |
| Topology | High frequency isolation (for battery) |
| Operating Ambient Temperature Range | -40 ~ +60°C |
| Ingress Protection | IP66 |
| Max. Operation Altitude | 4000 m |
| Grid Connection Standard | NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA |
| Safety/EMC Standard | IEC/EN 62109-1/-2, EN 61000-6-2/-3 |
| Features | DC connection: MC4 plug (PV port) / Terminal Block (BAT port)AC connection: Terminal BlockDisplay: LED + APPCommunication: RS485, CAN, Optional: Wi-Fi, GPRS, LAN |
S6-EH1P8K-L-PRO – 8kW Hybrid Inverter | Best Solar Solution in Pakistan
Looking for a reliable 8kW hybrid inverter for your solar system? The Solis S6-EH1P8K-L-PRO is a single-phase energy storage inverter designed for residential and commercial solar installations. With advanced battery management, seamless UPS functionality, and high-efficiency solar utilization, this inverter ensures uninterrupted power supply and maximum energy savings.
Key Features of Solis S6-EH1P8K-L-PRO
✅ Smart Hybrid Technology – Works with both grid-tied and off-grid setups.
✅ Seamless Power Backup – Instant UPS switching (<4ms) for uninterrupted power.
✅ Peak Shaving Mode – Optimizes energy usage, reducing electricity costs.
✅ Battery Compatibility – Supports Lithium-ion & Lead-Acid batteries (40-60V).
✅ High Charge/Discharge Current – Up to 190A for efficient battery usage.
✅ Advanced MPPT Technology – Ensures maximum solar energy harvesting.
✅ Smart Monitoring – Wi-Fi, GPRS, RS485, and CAN for remote access.
✅ Weatherproof Design – IP66-rated for outdoor installations.
Technical Specifications
🔹 Max PV Power: 12.8kW (future-proof for expansion).
🔹 Max. Efficiency: >96.9% for minimal energy loss.
🔹 Battery Power: 8kW with up to 190A charge/discharge current.
🔹 Surge Power Handling: 200% overload for 10 seconds.
🔹 Grid Voltage: 220V / 230V (single-phase).
🔹 Cooling System: Intelligent fan cooling for optimal performance.
🔹 Safety Protections: DC reverse polarity, AFCI (Arc Fault Protection), Ground Fault Monitoring.
Why Choose Comfort Solar?
At Comfort Solar, we provide professional solar installation services across Pakistan. Our affordable pricing, expert guidance, and premium quality installations ensure the best solar solutions for your home or business.
📞 For Pricing & Installation: Call/WhatsApp: 0316 622 5526
🌍 Visit Our Website: ComfortSolar.pk
📍 Location: Islamabad, Pakistan
Upgrade to a powerful and efficient 8kW hybrid inverter today! Contact us now!
