Additional information

Max. Apparent Output Power (Grid Side)	3.3 kVA, 4 kVA, 5.5 kVA, 6.6 kVA
Max. Apparent Output Power (Back-up)	2 times of rated power, 10 s
Rated Output Voltage (Back-up)	1/N/PE, 220 V / 230 V
Rated Output Current (Back-up)	13.6 A / 13.0 A, 16.4 A / 15.7 A, 22.7 A / 21.7 A, 27.3 A / 26.1 A
Recommended Max. PV Array Size	10 kW, 12 kW, 6 kW, 7.2 kW
Max. Usable PV Input Power	4.8 kW, 5.76 kW, 8 kW, 9.6 kW
Max. Input Voltage	600 V
Rated Voltage	330 V
Start-up Voltage	90 V
MPPT Voltage Range	90-520 V
Max. Input Current	16 A / 16 A
Max. Short Circuit Current per MPPT	24 A / 24 A
MPPT number/Max.input strings number	2/2
Battery Type	Li-ion / Lead-acid
Battery Voltage Range	40-60 V
Max. Charge / Discharge Power	3 kW, 3.6 kW, 5 kW, 6 kW
Max.charge/discharge current(A)	112 A, 135 A, 70 A, 80 A
Communication	CAN/RS485
Rated Output Power (Grid Side)	3 kW, 3.6 kW, 5 kW, 6 kW
Operation Phase	1/N/PE
Rated Grid Voltage	220 V / 230 V
Rated Grid Frequency	50 Hz / 60 Hz
Rated Grid Output Current	13.6 A / 13.0 A, 16.4 A / 15.7 A, 22.7 A / 21.7 A, 27.3 A / 26.1 A
Max. Output Current (Grid Side)	15 A, 20 A, 25 A, 30 A
Power Factor	>0.99 (0.8 leading – 0.8 lagging)
THDi	<2%
Input Voltage Range (Grid Side)	187-253 V
Max. Input Current (Grid Side)	20 A, 25 A, 32 A, 40 A
Frequency Range	45-55 Hz / 55-65 Hz
Rated Output Power (Back-up)	3 kW, 3.6 kW, 5 kW, 6 kW
Back-up Switch Time	<4 ms
Rated Frequency (Back-up)	50 Hz / 60 Hz
Max. Output Current (Back-up)	15 A, 20 A, 25 A, 30 A
Max. AC Passthrough Current	35 A, 40 A
THDv (@linear load)	<2%
Max. Efficiency	>96.9%
EU Efficiency	>96.5%
DC Reverse Polarity Protection	Yes
Ground Fault Monitoring	Yes
Integrated AFCI (DC Arc-Fault Circuit Protection)	Yes (1)
Protection Class/Over Voltage Category	I/II (PV and BAT), III (MAINS and BACKUP and GEN)
Dimensions (WHD)	406560205 mm
Weight	24 kg
Topology	High frequency isolation (for battery)
Operating Ambient Temperature Range	-40 ~ +60°C
Ingress Protection	IP66
Max. Operation Altitude	4000 m
Grid Connection Standard	NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA
Safety/EMC Standard	IEC/EN 62109-1/-2, EN 61000-6-2/-3
Features	DC connection: MC4 plug (PV port) / Terminal Block (BAT port)AC connection: Terminal BlockDisplay: LED + APPCommunication: RS485, CAN, Optional: Wi-Fi, GPRS, LAN

Description

Solis 6KW Single Phase LV Hybrid Inverter

Name: Solis Hybrid S6-EH1P (6 kw)K-L-PLUS LCD Model - Comfort Solar
Price: 240000 PKR
Availability: InStock

For the latest stock availability and pricing, please visit ComfortSolar.pk or contact us on WhatsApp: +923166225526 advance payment only.

Product Overview:

The Solis 6 KW Single Phase LV Hybrid Inverter is an advanced solar inverter designed to provide seamless energy conversion, backup power, and enhanced efficiency. Ideal for residential and small commercial applications, this hybrid inverter offers multiple power backup options, intelligent load management, and a high-efficiency conversion system.

🔹 Generator-Compatible – Works efficiently during grid outages by integrating with a backup generator.

🔹 Dual Backup Ports – Intelligent load control for critical and non-critical power needs.

🔹 Microgrid Capability – Can operate with multiple inverters to form an independent microgrid.

🔹 Ultra-Fast Switchover – Automatic transition in less than 4 ms, ensuring an uninterrupted power supply.

🔹 200% Overload Capability – Handles power surges for 10 seconds without affecting load performance.

🔹 Reliable Performance – Ensures stable power even with weak grids or fluctuating generator supply.

For orders and technical support, visit ComfortSolar.pk or WhatsApp: +923166225526.

Technical Specifications:

🔹 DC Input (PV Side)

Recommended Max. PV Array Size: 12 kW
Max. Usable PV Input Power: 9.6 kW
Max. Input Voltage: 500V
Rated Voltage: 330V
Start-Up Voltage: 90V
MPPT Voltage Range: 90V – 435V
Max. Input Current: 32A (2 Inputs of 16A Each)
MPPT Trackers: 2

🔹 Battery Compatibility

Battery Type: Li-ion / Lead-acid
Battery Voltage Range: 40V – 60V
Max. Charge / Discharge Power: 6 kW
Max. Charge / Discharge Current: 135A
Communication: CAN / RS485

🔹 AC Output (Grid Side)

Rated Output Power: 6 kW
Max. Apparent Output Power: 6 kVA
Rated Grid Voltage: 220V / 230V
Rated Grid Frequency: 50Hz / 60Hz
Power Factor: > 0.99
THDi: < 2%

🔹 AC Input (Grid Side)

Input Voltage Range: 187V – 253V
Max. Input Current: 40A
Frequency Range: 45Hz – 55Hz / 55Hz – 65Hz

🔹 AC Output (Backup Mode)

Rated Output Power: 6 kW
Max. Apparent Output Power: Twice the Rated Power for 10 Seconds
Switchover Time: < 4ms
Rated Output Voltage: 220V / 230V
Rated Frequency: 50Hz / 60Hz

🔹 Efficiency & Protections

Max. Efficiency: 96.2%
EU Efficiency: 96.1%
Battery Charging Efficiency (PV/AC): 95.3% / 93.9%
Battery Discharging Efficiency: 93.8%
Protection Features:
✅ Ground Fault Monitoring

✅ DC Reverse Polarity Protection

✅ Integrated AFCI (Optional)

✅ IP66 Protection for Outdoor Installations

🔹 General Information

Dimensions: 335 × 560 × 253 mm
Weight: 23.5 kg
Cooling Method: Intelligent Fan Cooling
Operating Temperature: -40°C to +60°C
Installation Altitude: Up to 3000m
Certifications: IEC 62109, EN 61000-6-2/-3, NRS 097-2-1

Order Now from Comfort Solar!

We offer the best price for the Solis 6KW Hybrid Inverter. Check stock availability before placing an order.

📞 WhatsApp: +923166225526

🌍 Website: ComfortSolar.pk

Brand

Solis

Sunlife Solar also imports top-quality inverters tailored to the needs of the subcontinent. As a leading Tier 1 company, Sunlife Solar supports Pakistan's solar industry by importing and supplying high-quality solar modules. For access to the full range of Sunlife Solar products, including their advanced PV modules and inverters, visit our website, "Comfort Solar," where you can explore and purchase their offerings to meet your energy requirements.

Established in 2005, Solis (Stock Code: 300763.SZ) is one of the largest and most experienced manufacturers of solar inverters globally. Through its Solis brand, Ginlong offers cost-effective inverter solutions for residential, commercial, and utility-scale users, supporting homeowners, businesses, power producers, and renewable energy investors worldwide. The company's inverters utilize advanced string technology, ensuring high reliability and performance validated by stringent international certifications.
