Additional information
Recommended max. PV power | 38 kW, 45 kW, 49.5 kW, 54 kW, 60 kW |
---|---|
Max. Input Voltage | 1100 V |
Rated Voltage | 600 V |
Start-up Voltage | 180 V |
MPPT Voltage Range | 200-1000 V |
Max. Input Current | 32 A / 32 A / 32 A, 4*32 A |
Max. Short Circuit Current per MPPT | 4*50 A, 50 A / 50 A / 50 A |
MPPT number/Max.input strings number | 3/6, 4/8 |
Rated Output Power | 25 kW, 30 kW, 33 kW, 36 kW, 40 kW |
Max. Apparent Output Power (Grid Side) | 27.5 kVA, 33 kVA, 36.3 kVA, 39.6 kVA, 44 kVA |
Rated Grid Voltage | 3/N/PE, 220 V / 380 V, 230 V / 400 V |
Rated Grid Frequency | 50 Hz / 60 Hz |
Rated Grid Output Current | 38.0 A / 36.1 A, 45.6 A / 43.3 A, 50.1 A / 47.6 A, 54.7 A / 52.0 A, 60.8 A / 57.7 A |
Max. Output Current | 41.8 A, 50.2 A, 55.1 A, 60.2 A, 66.9 A |
Power Factor | >0.99 (0.8 leading – 0.8 lagging) |
THDi | <3% |
Max. Efficiency | 98.5%, 98.6%, 98.7% |
EU Efficiency | 98.1%, 98.2%, 98.3% |
DC Reverse Polarity Protection | Yes |
Max. Output Power | 27.5 kW, 33 kW, 36.3 kW, 39.6 kW, 44 kW |
Short circuit protection | Yes |
Output over current protection | Yes |
Surge Protection | DC Type II / AC Type II |
Grid Monitoring | Yes |
Anti-islanding Protection | Yes |
Temperature protection | Yes |
Strings monitoring | Yes |
I/V Curve scanning | Yes |
Integrated PID recovery | Optional |
Integrated AFCI (DC Arc-Fault Circuit Protection) | Yes (1) |
Integrated DC switch | Optional |
Dimensions (W*H*D) | 647*629*252 mm |
Weight | 37 kg |
Self-Consumption Night | <1 W |
Operating Ambient Temperature Range | -25 ~ +60°C |
Relative Humidity | 0-100% |
Ingress Protection | IP66 |
Cooling Concept | Natural Convection |
Max. Operation Altitude | 4000 m |
Safety/EMC Standard | IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4 |
DC connection | MC4 connector |
Topology | Transformerless |
AC Connection | OT terminal |
Display | LCD |
Communication | RS485, Optional: Wi-Fi, GPRS |
