Additional information
The rated power | 1200VA/1000W, 2000VA/1600W, 3000VA/2700W |
---|---|
Voltage | 230VAC |
Selectable Voltage Range | 170-280VAC (UPS),90-280VAC (Appliances) |
Frequnecy Range | 50Hz/60Hz (Auto sensing) |
AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
Surge Power | 2000VA, 6000VA |
Power Factor | 0.8, 0.9 |
Efficiency(Peak) | > 90% |
Transfer Time | 10ms (UPS), 20ms (Appliances) |
Wave form | Pure Sine Wave |
No load current | 1.0A |
Battery Voltage | 12VDC, 24VDC |
Low battery alarming voltage | 11VDC, 22VDC |
Low battery cut off protection voltage | 10.5VDC, 21VDC |
Low battery recovery voltage | 11.5VDC, 23VDC |
Floating Charge Voltage | 13.5.VDC, 27VDC |
Overcharge Protection | 16VDC, 32VDC |
Maximum PV Array Power | 2000W, 3000W |
MPPT Range Operation Vol | 30-400VDC |
Best PV range | 120-400VDC, 30-400VDC |
Maximum PV Array Open Circuit Voltage | 400VDC |
Number of MPPT Trackers/Maximum Input Current | 80A |
Maxmum AC Charge Current | 60A |
Maxmum Efficiency | 98% |
Best Panel configuration | 550W 2-3PCS in 1 S, 550W 2-4 PCS in 1 S, 550W 2-5 PCS in 1 S |
Products Dimension, D*W*H(mm) | 400mm*306mm*103mm |
Packing size, D*W*H(mm) | 460mm*391mm*174mm |
Net Weight (kgs) | 4.4KG, 5.4KG |
G.W. kg | 5.1KG, 6.1KG |
Communication Interface | RS232/GPRS/ Optional WIFI |
Humidity | 5% to 95% Relative Humidity (Non-Condensing) |
Operation temperature | -10℃-50℃ |
