Original price was: ₨ 490,000.₨ 480,000Current price is: ₨ 480,000.
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Battery Management System (BMS) | Yes |
|---|---|
| Number of Strings Per MPP Tracker | 18 A x 2, 18 A x 2, 18 A x 2, 2 / A: 2, B: 2, 2 / A: 2, B: 2 |
| Parallel operation with 6 units | Yes |
| Phase | 1-phase in / 1-phase out, Three Phase |
| Maximum PV Input Power | 11000 W, 14500 W, 16000 W, 22500 W, 9000 W |
| Rated Output Power | 10000 W, 12000 W, 15000 W, 6000VA/6000W, 8000VA/8000W |
| MAXIMUM CHARGING POWER | 10000 W, 11000 W, 12000 W, 15000 W, 6000 W |
| Nominal DC Voltage/Maximum DC Voltage | 500 VDC, 720 VDC / 1000 VDC |
| Start-up Voltage/Initial Feeding Voltage | 320 VDC / 350 VDC, 80 VDC / 150 VDC |
| MPP voltage range | 120 VDC ~ 400 VDC, 350 ~ 950 VDC |
| Number of MPP Trackers / Maximum Input Current | 2 / 18A, 2 / A: 27A, B: 27A |
| Nominal Output Voltage | 220/230/240 VAC |
| Output Voltage Range | 184 – 264.5 VAC or 195.5 – 253 VAC or 184 – 264.4 VAC (Selectable) |
| Nominal Output Current | 14.5 A per phase, 17.4 A per phase, 26A, 36A |
| Power Factor Range | 0.9 lag ~ 0.9 lead |
| Surge Power | 12000VA, 16000VA, 20000VA, 24000VA, 30000VA |
| No Load Power Consumption | < 60W, < 85W |
| Maximum Conversion Efficiency( Solar to AC) | 95%, 96% |
| European Efficiency @ Vnominal | 91% |
| AC Start-up Voltage/Auto Restart Voltage | 120 – 140 VAC / 180 VAC, 60 – 80 VAC / 180 VAC |
| Acceptable Input Voltage Range | 170 – 280 VAC (For Computers) 90 – 280 VAC (For Home Appliances), 170 – 290 VAC per phase |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
| Output Waveform | Pure Sine Wave |
| Transfer Time | 10 ms (For Personal Computers) / 20 ms (For Home Appliances) |
| Efficiency (DC to AC) | 91% |
| Battery Voltage Range | 40 ~ 62 VDC |
| Maximum Charging Current | 120 A, 150 A, 200 A, 250 A, 300 A |
| Solar Charger Type | MPPT |
| Dimension, D x W x H (mm) | 192 x 385 x 665, 210 x 435 x 665, 255 x 660 x 750 |
| Net Weight (kgs) | 28, 32, 73 |
| Communication Port | RS-232, RS-485, USB, CAN and Wi-Fi |
| Intelligent Slot | Optional for SNMP and Modbus cards |
| Parallel Capability | YES, 6 units, YES, 9 units |
| Humidity | 0 ~ 100% RH (No condensing) |
| Operating Temperature | -25 to 60°C |
| Storage Temperature | -15°C to 60°C |
| Altitude | 0 ~ 1000 m |
| Selectable input voltage range for home appliances and personal computers | Yes |
| Compatible to Utility Mains or generator input | Yes |
| IP65 waterproof and dustproof | Yes |
| Dual outputs for smart load management | Yes |
| Reserved communication port for BMS (RS485, CAN-BUS or RS232) | Yes |
| Replaceable fan design for ease of maintenance | Yes |
| Selectable high power charging current | Yes |
| Battery independent design | Yes |
| Timer and prioritization | Yes |
| Batteryless Operation | Yes |
| Dual Output Grid Feeding | Yes |
| In Built Wi-Fi | Yes |
