Original price was: ₨ 880,000.₨ 870,000Current price is: ₨ 870,000.
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| MPP voltage range | 120 VDC ~ 400 VDC, 350 ~ 950 VDC |
|---|---|
| Number of Strings Per MPP Tracker | 18 A x 2, 18 A x 2, 18 A x 2, 2 / A: 2, B: 2, 2 / A: 2, B: 2 |
| Number of MPP Trackers / Maximum Input Current | 2 / 18A, 2 / A: 27A, B: 27A |
| Maximum PV Input Power | 11000 W, 14500 W, 16000 W, 22500 W, 9000 W |
| Rated Output Power | 10000 W, 12000 W, 15000 W, 6000VA/6000W, 8000VA/8000W |
| MAXIMUM CHARGING POWER | 10000 W, 11000 W, 12000 W, 15000 W, 6000 W |
| Nominal DC Voltage/Maximum DC Voltage | 500 VDC, 720 VDC / 1000 VDC |
| Phase | 1-phase in / 1-phase out, Three Phase |
| Start-up Voltage/Initial Feeding Voltage | 320 VDC / 350 VDC, 80 VDC / 150 VDC |
| Nominal Output Voltage | 220/230/240 VAC |
| Output Voltage Range | 184 – 264.5 VAC or 195.5 – 253 VAC or 184 – 264.4 VAC (Selectable) |
| Nominal Output Current | 14.5 A per phase, 17.4 A per phase, 26A, 36A |
| Power Factor Range | 0.9 lag ~ 0.9 lead |
| Surge Power | 12000VA, 16000VA, 20000VA, 24000VA, 30000VA |
| No Load Power Consumption | < 60W, < 85W |
| Maximum Conversion Efficiency( Solar to AC) | 95%, 96% |
| European Efficiency @ Vnominal | 91% |
| AC Start-up Voltage/Auto Restart Voltage | 120 – 140 VAC / 180 VAC, 60 – 80 VAC / 180 VAC |
| Acceptable Input Voltage Range | 170 – 280 VAC (For Computers) 90 – 280 VAC (For Home Appliances), 170 – 290 VAC per phase |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
| Output Waveform | Pure Sine Wave |
| Transfer Time | 10 ms (For Personal Computers) / 20 ms (For Home Appliances) |
| Efficiency (DC to AC) | 91% |
| Battery Voltage Range | 40 ~ 62 VDC |
| Maximum Charging Current | 120 A, 150 A, 200 A, 250 A, 300 A |
| Solar Charger Type | MPPT |
| Dimension, D x W x H (mm) | 192 x 385 x 665, 210 x 435 x 665, 255 x 660 x 750 |
| Net Weight (kgs) | 28, 32, 73 |
| Communication Port | RS-232, RS-485, USB, CAN and Wi-Fi |
| Intelligent Slot | Optional for SNMP and Modbus cards |
| Parallel Capability | YES, 6 units, YES, 9 units |
| Humidity | 0 ~ 100% RH (No condensing) |
| Operating Temperature | -25 to 60°C |
| Storage Temperature | -15°C to 60°C |
| Altitude | 0 ~ 1000 m |
