Original price was: ₨ 485,000.₨ 475,000Current price is: ₨ 475,000.
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Battery Management System (BMS) | Yes |
|---|---|
| Parallel operation with 6 units | Yes |
| Built-in DC output for DC fan, LED bulb, router and so on | Yes |
| Built-in Wi-Fi for mobile monitoring (Android/iOS App available) | Yes |
| Configurable AC/PV output usage timer and prioritization | Yes |
| Phase | Single Phase |
| Maximum PV Input Power | 11000 W (5500 W x 2), 13000 W (6500 W x 2), 5600 W, 7200 W, 7500 W, 8000 W |
| Rated Output Power | 11000 W, 4000 W, 6000 W, 8000 W |
| Nominal DC Voltage/Maximum DC Voltage | 500 VDC |
| Start-up Voltage/Initial Feeding Voltage | 120 VDC / 150 VDC |
| MPP voltage range | 90 ~ 450 VDC |
| Number of MPP Trackers / Maximum Input Current | 1 / 27A (MAX 40A) |
| Nominal Output Voltage | 220/230/240 VAC |
| Output Voltage Range | 170-280 VAC (For Personal Computers) / 90-280 VAC (For Home Appliances) |
| Nominal Output Current | 18 A, 26 A, 35 A, 48 A |
| Power Factor | > 0.99 |
| Maximum Conversion Efficiency( Solar to AC) | 95% |
| AC Start-up Voltage/Auto Restart Voltage | 120 – 140 VAC / 180 VAC |
| Acceptable Input Voltage Range | |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| Output Waveform | Pure Sine Wave |
| Transfer Time | 10 ms (For Personal Computers) / 20 ms (For Home Appliances) |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
| Maximum Solar Charging Current | 150A |
| Maximum AC Charging Current | 150A |
| Surge Power | 12000VA, 16000VA, 22000VA, 8000VA |
| Dimension, D x W x H (mm) | 119 x 313.6 x 457.5, 120 x 295 x 468, 140 x 295 x 468, 140 x 365 x 468, 158.4 x 503.6 x 530.8 |
| Net Weight (kgs) | 11, 12, 20 |
| Parallel Function | Yes, 6 units, Yes, 9 Units |
| Communication Port | USB/RS232/RS485/Wi-Fi/Dry-contact |
| Humidity | 0 ~ 90% RH (No condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
| Compatible to Utility Mains or generator input | Yes |
| Built-in Anti-Dust Kit | Yes |
| Dual outputs for smart load management | Yes |
| Maximum PV input current increases to 27A | Yes |
| Wide PV input voltage range 90VDC ~ 450VDC | Yes |
| Status indication with RGB lights | Yes |
| Supports USB On-the-Go function | Yes |
| Battery independent design | Yes |
| Reserved communication port for BMS (RS485, CAN-BUS or RS232) | Yes |
| Replaceable fan design for ease of maintenance | Yes |
| Batteryless Operation | Yes |
| Dual Output Grid Feeding | Yes |
| In Built Wi-Fi | Yes |
