12kW high-efficiency on-grid solar inverter
MPPT tracking efficiency up to 99.9%
Maximum PV input power: 15,600W
Wide MPPT voltage range: 180V – 1000V
Supports modern 182mm & 210mm solar modules
IP66 waterproof and dustproof protection
Low harmonic distortion (<2%)
Intelligent fan cooling with low noise (<45dB)
WiFi / RS485 communication support
5-year replacement warranty
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
The itel IGT-12KTA is a high-performance 12kW on-grid solar inverter designed for residential and commercial solar systems. It features advanced MPPT technology with ultra-high tracking efficiency to maximize solar energy production. With a wide input voltage range and strong compatibility with modern high-power solar modules, it ensures stable and efficient operation.Its IP66-rated waterproof and dustproof design makes it suitable for outdoor installation in harsh environments. The inverter delivers reliable grid synchronization, low harmonic distortion, and quiet operation, making it an ideal solution for efficient solar power generation
| itel IGT-12KTA 12kW On-Grid Solar Inverter Specifications | |
|---|---|
| Efficiency | |
| MPP Tracking Efficiency | 99.9% |
| Max. Conversion Efficiency | 98.7% |
| European Efficiency | 98.2% |
| PV Input | |
| Max. PV Input Power | 15600W |
| Max. DC Input Voltage | 1100V |
| MPPT Voltage Range | 180V ~ 1000V |
| Max. Input Current | 18A / 18A |
| MPP Trackers | 2 |
| Max. Input String Number per MPPT | 1 / 1 |
| AC Output (On-Grid) | |
| Nominal Output Power | 12000W |
| Max. Output Apparent Power | 13200VA |
| Nominal Output Voltage | 230VAC / 400VAC (3W+N+PE) |
| Max. Output Current | 20A |
| Output Voltage Range | 180VAC ~ 280VAC (L-N) |
| Nominal Frequency | 50Hz / 60Hz |
| Output Frequency Range | 45Hz ~ 65Hz |
| Power Factor | 0.99 |
| Power Factor Adjustment Range | 0.8 Leading to 0.8 Lagging |
| Total Current Harmonic Distortion | <2% |
| General | |
| Dimensions (D × W × H) | 204 × 450 × 427 mm |
| Net Weight | 15.3 kg |
| Max. Operating Altitude | 4000m (>2000m Power Derating) |
| Communication | WiFi / RS485 |
| Power Consumption at Night | <1W |
| Cooling Method | Intelligent Fan Cooling |
| Noise | <45dB |
| Authentication Level | IEC62109-1, IEC62109-2, IEC61683, IEC62116, IEC61727 |
| Operating Temperature Range | -25°C ~ +60°C (>45°C Power Derating) |
| Ingress Protection | IP66 |
| Protection | |
| PV Reverse Protection | Yes |
| Residual Current Monitoring | Yes |
| Overvoltage Protection | Yes |
| Overload Protection | Yes |
| Short Circuit Protection | Yes |
| Over Temperature Protection | Yes |
| Surge Protection | DC: Type II / AC: Type III |
| Insulation Impedance Detection | Yes |
