Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Maximum PV Input Power | 5200W |
|---|---|
| Rated Output Power | 3600W / 3600VA |
| Maximum Solar Charging Current | 120 A |
| Maximum DC Voltage | 500VDC |
| Nominal DC Voltage | 24 VDC |
| Initial Feeding Voltage | 120VDC |
| Start-up Voltage | 90VDC |
| MPPT Voltage Range | 90VDC ~ 450VDC |
| Number of MPPT Trackers | 1 |
| Maximum input current | 23 Amp |
| Nominal Output Voltage | 220/230/240VAC |
| Output Voltage Range | 195.5 ~ 253VAC |
| Nominal Output Current | 15.7 Amp |
| Power Factor | >0.99 |
| Feed-in Grid Frequency Range | 49-51 +-1Hz |
| Maximum Conversion Efficiency( Solar to AC) | 98% |
| Full Load | 3600W |
| Maximum Main Load | 3600W |
| Maximum Second Load Upto(Battery Mode) | 1200W |
| Main Load Cutt Off Voltage | 22VDC |
| Main Load Return Voltage | 26VDC |
| AC Start-up Voltage | 120-140VAC |
| Auto Restart Voltage | 180VAC |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC |
| Maximum AC Input Current | 30A |
| Nominal operating frequency | 50/60Hz |
| Surge Power | 7200W |
| Output Waveform | Pure Sine Wave |
| Efficiency (DC to AC) | 94% |
| Maximum AC Charging Current | 100 A |
| Total Current | 160 A |
| Dimensions D × W × H(mm) | 423×334×110 |
| Net Weight (kg) | 9 |
| Communication Port | Rs232/WIFI/GPRS |
| Operating Temperature | -10~50C |
