Description
Introducing the VS-AU series PWM Charge Controller, featuring an LCD display and dual USB ports, designed for reliable and cost-effective solar energy management. Available at Comfort Solar, this controller is ideal for applications where the difference between solar panel working voltage and battery voltage is minimal. It provides efficient energy conversion and essential features for rural electrification, home power systems, and more.
Key Features:
Specifications:
Why Choose Comfort Solar?
At comfortsolar.pk, we specialize in providing affordable and efficient solar solutions tailored to your specific needs. The VS-AU series PWM Charge Controller exemplifies our dedication to quality, reliability, and customer satisfaction. Choose our products for sustainable energy solutions and long-term performance.
Call to Action:
Ready to enhance your solar energy system with the VS-AU series PWM Charge Controller? Visit comfortsolar.pk today to learn more about our products. For inquiries or to place an order, contact us directly on WhatsApp at 03166225526. Start your journey towards efficient solar energy management with Comfort Solar!
| Nominal system voltage | 12/24/36/48VDC Auto, 12/24VDC Auto |
|---|---|
| Battery Type | Sealed(Default)/Gel/Flooded |
| Battery input voltage range | 9V～32V, 9V～64V |
| Rated charge current | 10A, 20A, 30A, 45A, 60A |
| Rated discharge current | 10A, 20A, 30A, 45A, 60A |
| Max. PV open circuit voltage | 50V, 96V |
| Equalization voltage | Sealed:14.6V,Flooded:14.8V |
| Boost voltage | Gel:14.2V,Sealed:14.4V,Flooded:14.6V |
| Float voltage | Gel/Sealed/Flooded:13.8V |
| Low Voltage Reconnect Voltage | Gel/Sealed/Flooded:12.6V |
| Low Voltage Disconnect Voltage | Gel/Sealed/Flooded:11.1V |
| Self-consumption | ≤9.2mA/12V;≤11.7mA/24V;≤14.5mA/36V;≤17mA/48V |
| USB output | 5VDC/2.4A(Total) |
| Temperature compensation | -3mV/℃/2V（25℃） |
| Relative Humidity | ≤95%, N.C. |
| Enclosure | IP30 |
| Grounding | Common Positive |
| Operating Temperature Range | -25℃～+55℃ |
| Dimensions(LxWxH)(mm) | 142×85×41.5, 160×94.9×49.3, 181×100.9×59.8, 194×118.4×63.8, 214×128.7×72.2 |
| Net Weight | 0.22kg, 0.35kg, 0.55kg, 0.58kg, 0.76kg, 0.88kg, 1.02kg, 1.04kg |
