EPEVER 10A MPPT Solar Charge Controller, 12V/24V Auto Work
Introducing the 2024 New Upgraded Tracer-AN MPPT Solar Charge Controller, designed for enhanced functionality and advanced technology by Comfort Solar, an official authorized supplier of EPEVER products.
Key Features:
Why Choose Comfort Solar?
Comfort Solar, as an EPEVER Official Authorized Supplier (GolandCentury), provides expert technical support and reliable solar solutions. For inquiries about solar systems or product details, contact us at 03166225526 or visit comfortsolar.pk.
| Nominal system voltage | 12/24VDC/Auto |
|---|---|
| Battery Type | Lead-acid (Sealed/Gel/Flooded)/Lithium (LiFePO4/Li(NiCoMn)O2)/User |
| Battery input voltage range | 8～32V |
| Rated charge current | 10A, 20A, 30A, 40A |
| Rated discharge current | 10A, 20A, 30A, 40A |
| Rated charge power | Â Â Â 260W/12VÂ Â Â Â 520W/24V, Â Â Â 130W/12VÂ Â Â 260W/24V, Â Â 130W/12VÂ Â Â 260W/24V, Â Â 260W/12VÂ Â Â 520W/24V, Â Â 390W/12VÂ Â 780W/24V, Â Â 520W/12VÂ Â Â 1040W/24V |
| Max. conversion efficiency | ≤98.0% |
| Tracking efficiency | ≥99.5% |
| Max. PV open circuit voltage | 100V（At minimum operating environment temperature）; 92V（At 25℃ environment temperature）, 60V（At minimum operating environment temperature）; 46V（At 25℃ environment temperature） |
| MPP voltage range | (Battery voltage +2V)～36V, (Battery voltage +2V)～72V |
| Equalization voltage | Sealed:14.6V,Flooded:14.8V,User-defined:9-17V |
| Boost voltage | Gel:14.2V,Sealed:14.4V,Flooded:14.6V,User-defined:9-17V |
| Float voltage | Gel/Sealed/Flooded:13.8V,User-defined:9-17V |
| Low Voltage Reconnect Voltage | Gel/Sealed/Flooded:12.6V,User-defined:9-17V |
| Low Voltage Disconnect Voltage | Gel/Sealed/Flooded:11.1V,User-defined:9-17V |
| Self-consumption |   ≤12mA |
| Temperature compensation( for lead-acid battery) | -3mV/℃/2V (Default) |
| Relative Humidity | ≤95%, N.C. |
| Enclosure | IP30 |
| Communication Interface | RS485(RJ45) |
| Grounding | Common Negative |
| Operating Temperature Range | -25℃～+45℃(100% input and output) |
| Dimensions(LxWxH)(mm) | 172×139×44, 220×154×52, 228×164×55, 252×180×63 |
| Net Weight | 0.57kg, 0.94kg, 1.26kg, 1.65kg |
