Additional information
Temperature compensation coefficient | -3mV/℃/2V (Lithium batteries don’t have temperature compensation coefficient) |
---|---|
Work temperature (Above 45℃, please operate in derating) | -40℃~ +50℃ (Above 45℃, please operate in derating) |
Communication | RS485/BLE |
Rated system voltage | 12/24VDC Auto( Lithium battery cannot automatically identify system voltage) |
Battery work voltage range | 8~32VDC |
Rated charge/discharge current | 20A, 30A |
Rated charge power | 260W/12V;520W/24V, 390W/12V; 780W/24V |
Max. PV open circuit voltage | 100V (at minimum operating environment temperature) 92V( at 25℃ environment temperature ), 60V (at minimum operating environment temperature) 46V( at 25℃ environment temperature ) |
MPP voltage range | (Battery voltage +2V) ~ 36V, (Battery voltage +2V) ~ 72V |
Battery Type | Lead-acid battery: Sealed(Default) / Gel / Flooded/User; Lithium battery: LiFePO4/ Li-NiCoMn/User |
Lead-acid | Equalize Charging Voltage, Sealed: 14.6V, Gel: No, Flooded: 14.8V, User: 9-17V ( ×2/24V) |
Boost Charging Voltage | Sealed: 14.4V, Gel: 14.2V, Flooded: 14.6V, User: 9-17V ( ×2/24V) |
Float Charging Voltage | Sealed/Gel/Flooded: 13.8V, User: 9-17V ( ×2/24V) |
Low Voltage Reconnect Voltage | LiFePO4: 12.8V, Li-NiCoMn: 10.5V, User: 9-17V ( ×2/24V) |
Low Voltage Disconnect Voltage | LiFePO4: 11.1V, Li-NiCoMn: 9.3V, User: 9-17V ( ×2/24V) |
Lithium | Boost Charging Voltage, LiFePO4: 14.5V, Li-NiCoMn: 12.5V, User: 9-17V ( ×2/24V) |
Self-consumption | ≤10mA(12V); ≤7mA(24V), ≤15mA(12V); ≤9mA(24V) |
Enclosure | IP68 |
Dimension (L x W x H) | Tracer5206CPN: 150.6mm × 130mm × 50mmTracer5206CPN(BLE): 159mm × 130mm × 50mm, Tracer7810CPN: 158.6mm × 141mm × 51.5mmTracer7810CPN(BLE): 167mm × 141mm × 51.5mm |
Mounting hole size | Φ4.5mm |
Mounting size (L x W) | 121mm × 120mm, 132mm × 120mm |
Power cable (PV/BAT/LOAD) | PV: 11AWG, BAT/LOAD: 10AWG |
Net Weight | 1.25kg, 2.60kg |
