Output Power: 20 kW
Max Efficiency: 98.6%
MPPTs: 2
Max DC Input Current: 2 × 40A
AC Output Current: 30.4 A
Cooling: Intelligent Forced Air
Protection: AFCI, SPD II, reverse polarity
Easy-to-install, IP66-rated
Dimensions: 435 × 520 × 194 mm
Weight: 19 kg
Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
High-efficiency 20kW inverter for medium to large-scale solar systems. Offers higher current handling and improved safety features.
| Max. DC Voltage | 1100 VDC |
|---|---|
| Start-up DC Voltage | 180 VDC |
| Rated Input Voltage | 630 VDC |
| Max. Number of PV Strings | 4 |
| MPPTs | 2 |
| Max. Input Current/MPPT | 2×32 A |
| Rated Output Power | 20 kW |
| Rated Apparent Power | 20 kVA |
| Rated Output Voltage | 380/400 VAC |
| Rated Output Current | 30.4 A |
| Rated Output Frequency | 50/60 Hz |
| Total Harmonic Distortion (THD) | < 3% |
| Power Factor | 0.8 (Adjustable) |
| Max. Efficiency | 98.6% |
| Euro Efficiency | 98.0% |
| Protection Degree | IP66 |
| Cooling Method | Intelligent Air Cooling |
| Operating Temperature | -30°C to +60°C |
| Operating Altitude | 4000 m (derating above 2000 m) |
| DC Switch | Yes |
| Anti-Islanding Protection | Yes |
| Reverse Polarity Protection | Yes |
| Insulation Resistance Detection | Yes |
| Leakage Current Suppression | Yes |
| AC Output Over Current Protection | Yes |
| AC Short Circuit Protection | Yes |
| Display Type | LED Indicators & APP |
| Communication Interfaces | RS485 / Wi-Fi / Optional 4G |
| Dimensions | 435 x 520 x 194 mm |
| Weight | 19 kg |
| Connectors | Plug-type (Tool-free installation) |
| AFCI | Optional |
