Additional information
Max. DC Voltage | 1100 VDC |
---|---|
Start-up DC Voltage | 180 VDC |
Rated Input Voltage | 630 VDC |
Max. Number of PV Strings | 4 |
MPPTs | 2 |
Max. Input Current/MPPT | 2×32 A |
Rated Output Power | 15 kW |
Rated Apparent Power | 15 kVA |
Rated Output Voltage | 380/400 VAC |
Rated Output Current | 22.8 A |
Rated Output Frequency | 50/60 Hz |
Total Harmonic Distortion (THD) | < 3% |
Power Factor | 0.8 (Adjustable) |
Max. Efficiency | 98.5% |
Euro Efficiency | 98.0% |
Protection Degree | IP66 |
Cooling Method | Intelligent Air Cooling |
Operating Temperature | -30°C to +60°C |
Operating Altitude | 4000 m (derating above 2000 m) |
DC Switch | Yes |
Anti-Islanding Protection | Yes |
Reverse Polarity Protection | Yes |
Insulation Resistance Detection | Yes |
Leakage Current Suppression | Yes |
AC Output Over Current Protection | Yes |
AC Short Circuit Protection | Yes |
Display Type | LED Indicators & APP |
Communication Interfaces | RS485 / Wi-Fi / Optional 4G |
Dimensions | 435 x 520 x 194 mm |
Weight | 19 kg |
Connectors | Plug-type (Tool-free installation) |
AFCI | Optional |
