Due to high market volatility, prices for our products are subject to change.
The actual price will be provided once the customer contacts our sales representative via WhatsApp.
The product will be dispatched only after a partial deposit is made in our business account.
| Temperature compensation coefficient | -3mV/℃/2V (Lithium batteries don’t have temperature compensation coefficient) |
|---|---|
| Work temperature (Above 45℃, please operate in derating) | -40℃~ +50℃ (Above 45℃, please operate in derating) |
| Communication | RS485/BLE |
| Rated system voltage | 12/24VDC Auto( Lithium battery cannot automatically identify system voltage) |
| Battery work voltage range | 8~32VDC |
| Rated charge/discharge current | 20A, 30A |
| Rated charge power | 260W/12V;520W/24V, 390W/12V; 780W/24V |
| Max. PV open circuit voltage | 100V (at minimum operating environment temperature) 92V( at 25℃ environment temperature ), 60V (at minimum operating environment temperature) 46V( at 25℃ environment temperature ) |
| MPP voltage range | (Battery voltage +2V) ~ 36V, (Battery voltage +2V) ~ 72V |
| Battery Type | Lead-acid battery: Sealed(Default) / Gel / Flooded/User; Lithium battery: LiFePO4/ Li-NiCoMn/User |
| Lead-acid | Equalize Charging Voltage, Sealed: 14.6V, Gel: No, Flooded: 14.8V, User: 9-17V ( ×2/24V) |
| Boost Charging Voltage | Sealed: 14.4V, Gel: 14.2V, Flooded: 14.6V, User: 9-17V ( ×2/24V) |
| Float Charging Voltage | Sealed/Gel/Flooded: 13.8V, User: 9-17V ( ×2/24V) |
| Low Voltage Reconnect Voltage | LiFePO4: 12.8V, Li-NiCoMn: 10.5V, User: 9-17V ( ×2/24V) |
| Low Voltage Disconnect Voltage | LiFePO4: 11.1V, Li-NiCoMn: 9.3V, User: 9-17V ( ×2/24V) |
| Lithium | Boost Charging Voltage, LiFePO4: 14.5V, Li-NiCoMn: 12.5V, User: 9-17V ( ×2/24V) |
| Self-consumption | ≤10mA(12V); ≤7mA(24V), ≤15mA(12V); ≤9mA(24V) |
| Enclosure | IP68 |
| Dimension (L x W x H) | Tracer5206CPN: 150.6mm × 130mm × 50mmTracer5206CPN(BLE): 159mm × 130mm × 50mm, Tracer7810CPN: 158.6mm × 141mm × 51.5mmTracer7810CPN(BLE): 167mm × 141mm × 51.5mm |
| Mounting hole size | Φ4.5mm |
| Mounting size (L x W) | 121mm × 120mm, 132mm × 120mm |
| Power cable (PV/BAT/LOAD) | PV: 11AWG, BAT/LOAD: 10AWG |
| Net Weight | 1.25kg, 2.60kg |
About this item
EPEVER MPPT Solar Charge Controller 30A Tracer3210AN (Upgraded version)
Highlights: The Tracer3210AN is an upgraded MPPT solar charge controller capable of handling 12V and 24V battery systems with a maximum PV input voltage of 100V. It supports a wide range of battery types, including Gel, AGM, Flooded, Sealed batteries, as well as specific configurations for Lithium Batteries: LiFePO4 (4s/12V; 8s/24V) and Li(NiCoMn)O2 (3s/12V; 6s/24V).
Advanced MPPT Technology: Achieves efficiency no less than 99.5% with ultra-fast tracking speed and guaranteed tracking efficiency. The advanced MPPT control algorithm minimizes maximum power point loss rate and time, ensuring optimal solar energy conversion.
High-Quality Components: Utilizes components from international brands such as ST and IR, known for their high quality and low failure rate, ensuring long service life and robust performance.
Features:
Communication and Monitoring: The controller features an RS-485 communication bus interface with Modbus communication protocol, allowing monitoring and parameter setting via mobile phone app or PC software. It supports full-load operation without capacity drop within its working range.
Why Choose Comfort Solar?
Comfort Solar, an authorized supplier of EPEVER products through GolandCentury, offers expert guidance and support for your solar system needs. Contact us for personalized solar system suggestions and expert advice from our engineers.
Call to Action:
Visit comfortsolar.pk to explore the EPEVER MPPT Solar Charge Controller Tracer3210AN and other high-quality solar products. For inquiries and personalized solar system recommendations, contact us via WhatsApp at 03166225526. Start maximizing your solar energy efficiency with Comfort Solar!
